Hydraulic Rubber Hose SAE100 R4

SAE 100 R4 textile reinforced hydraulic hose is mainly for oil suction and delivery in the hydraulic systems. It consists of three parts: tube, reinforce and cover. The tube is made from high quality black, smooth and oil resistant synthetic rubber, making the hose widely used for oil delivery. The reinforcement is made from one layer or multiple layers of high strength braided textile with helix steel wire, making the hose have solid structure. The cover is made from high quality synthetic rubber, making the hose resistant to abrasion, corrosion, weather, ozone, aging and cut. Thus the hose haa a longer service life.

Descriptions:

SAE 100 R4 is a standard specification for low-pressure return lines used in hydraulic systems to suction and return petroleum and water-based fluids. The hose is made of oil-resistant rubber, capable of withstanding high temperature and pressure environments while maintaining flexibility and tensile strength.

SAE 100 R4 hoses are commonly used in industrial and automotive applications and are reliable for low-pressure oil lines.

Features:

Ozone Resistant, Flexible, Weathering Resistant

SpecificationsSpecifications:

Operating Temperature: -40°C-+100°C
Tube: Hydraulic Oil Resistant Synthetic Rubber
Reinforcement: High Tensile Synthetic Cord, Helix Steel Wire
Cover: Black, Fabric Wrapped, Excellently Resistant to Oil, Heat, Abrasion, Ozone and Weathering, Synthetic Rubber
Inner Diameter Sizes Ranging from 3/4” to 4”
Hose assemblies with couplings are available in custom length by request.

Applications:

Commonly Used in Oil Suction and Return Low Pressure Hydraulic Systems of Ship, Construction Machinery, Automobile, and Aircraft.

Hydraulic Hose STANDARD: SAE 100 R4
