Silicone Straight Meter Hose
Heating and Cooling Systems; CAC Charge-Air-Cooler (Hot & Cold side); Turbo Charger Systems & Custom Compressor; Intercooler or Intake & Inlet Piping foturbo/Super chargers. etc.
Silicone Straight Meter Hose
Construction:
Tube:100% High quality silicone
Reinforcement:4ply Polyester/Aramid/Glass fiber
Cover:silicon
Application:
Heating and Cooling Systems CAC Charge-Air-Cooler (Hot & Cold side) ,Turbo Charger Systems & Custom Compressor,Intercooler or Intake & Inlet Piping
foturbo/Superchargers. etc.
Characteristic:
1.No taste, no toxic, eco-friendly.
2.High temperature resistance,aging,operative temperature: – 40 ° C ~ 220 ° C
3.Having physical laziness,Good air permeability
4.We offer OEM/ODM, We can 3D design, produce according to your drawings
Temperature:-40ºC (-104 ºF )to +220ºC (+428 ºF )
| Item code | I.D. | Layer | Thickness (mm) |
Leg Length |
| mm | ||||
| RTSL006 | 6.5 | 4 | 4 | 1000 |
| RTSL008 | 8 | 4 | 4 | 1000 |
| RTSL009 | 9 | 4 | 4 | 1000 |
| RTSL010 | 10 | 4 | 4 | 1000 |
| RTSL012 | 12 | 4 | 4 | 1000 |
| RTSL014 | 14 | 4 | 4 | 1000 |
| RTSL016 | 16 | 4 | 4 | 1000 |
| RTSL018 | 18 | 4 | 4 | 1000 |
| RTSL020 | 20 | 4 | 4 | 1000 |
| RTSL024 | 24 | 4 | 4 | 1000 |
| RTSL026 | 26 | 4 | 4 | 1000 |
| RTSL030 | 30 | 4 | 4 | 1000 |
| RTSL032 | 32 | 4 | 4 | 1000 |
| RTSL034 | 34 | 4 | 4 | 1000 |
| RTSL036 | 36 | 4 | 4 | 1000 |
| RTSL038 | 38 | 4 | 4 | 1000 |
| RTSL040 | 40 | 4 | 5 | 1000 |
| RTSL042 | 42 | 4 | 5 | 1000 |
| RTSL045 | 45 | 4 | 5 | 1000 |
| RTSL048 | 48 | 4 | 5 | 1000 |
| RTSL050 | 51 | 4 | 5 | 1000 |
| RTSL057 | 57 | 4 | 5 | 1000 |
| RTSL060 | 60 | 4 | 5 | 1000 |
| RTSL063 | 63 | 4 | 5 | 1000 |
| RTSL070 | 70 | 4 | 5 | 1000 |
| RTSL076 | 76 | 4 | 5 | 1000 |
| RTSL080 | 80 | 4 | 5 | 1000 |
| RTSL089 | 89 | 4 | 5 | 1000 |
| RTSL102 | 102 | 4 | 5 | 1000 |
Size，working pressure and wall thickness can be customized as required。
