Silicone Heater Hose

Silicone Heater Hose exceeds the SAE J20 R3 Class A. The silicone hose is reinforced with 1-ply polyester fabric. It can also bear elevated temp. Such silicone hose has a work temp range of -54℃ to +200℃. Thus it’s ideal for coolant fluid and vacuum line service.

Silicone Heater Hose

Silicone Heater Hose

Construction:
Inner:100% High quality silicone
Cover:silicone
Reinforcement: Polyester/Aramid Braid
Color:Black/Red/Blue/Green/Yellow

Application:
mainly used in mine hydraulic support, oil exploration, suitable to engineer construction, crane transport, forging metallurgy, mining equipment, ships, injection molding machinery agricultural machinery various machine tools.
Characteristic:
1.100% Virgin silicone materials
2.Provides high pressure resistance and superior impulse resistance.
3.Provides superior oil resistance, heat resistance and aging resistance by using special synthetic rubber
4.Provides superior bonding in hose internal, soft use and small deformation under pressure
5.Provides superior kink resistance and fatigue resistance and longer services life
6.Working Pressure:0.3-1.2MPA
Temperature:-40ºC ( -104 ºF ) to +220ºC (+428 ºF )



Iterm Code I.D(mm) Reinforced Layer Thickness(mm) Iterm Code I.D(mm) Reinforced Layer Thickness(mm)
SHH08 8.0 2  4/5 SHH20 20.0 2  4/5
SHH10 10.0 2  4/5 SHH22 22.0 2  4/5
SHH12 12.0 2  4/5 SHH24 24.0 2  4/5
SHH13 13.0 2  4/5 SHH25 25.0 2  4/5
SHH14 14.0 2  4/5 SHH28 28.0 2  4/5
SHH16 16.0 2  4/5 SHH30 30.0 2  4/5
SHH18 18.0 2  4/5 SHH32 32.0 2  4/5

Sizeworking pressure and wall thickness can be customized as required
