PVC Suction Hose Applications:
drainage, and for transporting various powdery particles and liquids, it is widely used in civil and building works, agriculture, mining, construction, ship and fishery.
Pvc Suction Hose Features:
●Economical & flexible
●Abrasion & chemical resistant
●Impact & crush resistant
●Excellent bending radius
●Constructed with rigid spiral helix reinforcement
●Smooth inner construction for unrestricted flow of materials
PVC Suction Hose Temperature: -10℃(-50℉) to 65℃(+150℉)
PVC Suction hose
| Part No. | size | Inner Diameter | Thickness (mm) | Weight | Length (m/coil) | Volume |
| inch | mm | kg/m | m³/roll | |||
| 1901 | 3/4″ | 19 | 2 | 0.18 | 30 | |
| 1902 | 2.5 | 0.23 | 30 | |||
| 1903 | 3 | 0.28 | 30 | |||
| 2501 | 1″ | 25 | 2 | 0.23 | 30 | |
| 2502 | 2.5 | 0.29 | 30 | |||
| 2503 | 3 | 0.35 | 30 | |||
| 2504 | 3.5 | 0.41 | 30 | |||
| 3201 | 1-1/4″ | 32 | 2.5 | 0.36 | 30 | |
| 3202 | 3 | 0.4 | 30 | |||
| 3203 | 3.5 | 0.45 | 30 | |||
| 3204 | 4 | 0.5 | 30 | |||
| 3801 | 1-1/2″ | 38 | 2.5 | 0.48 | 30 | |
| 3802 | 3 | 0.54 | 30 | |||
| 3803 | 3.5 | 0.62 | 30 | |||
| 3804 | 4 | 0.7 | 30 | |||
| 5001 | 2″ | 50 | 2 | 0.55 | 30 | |
| 5002 | 3 | 0.7 | 30 | |||
| 5003 | 4 | 0.92 | 30 | |||
| 5004 | 4.5 | 1.1 | 30 | |||
| 6301 | 2-1/2″ | 63 | 3 | 0.88 | 30 | |
| 6302 | 3.5 | 0.95 | 30 | |||
| 6303 | 4 | 1.18 | 30 | |||
| 6304 | 4.5 | 1.3 | 30 | |||
| 7501 | 3″ | 75 | 3 | 1.1 | 30 | |
| 7502 | 3.5 | 1.25 | 30 | |||
| 7503 | 4 | 1.38 | 30 | |||
| 7504 | 4.5 | 1.5 | 30 | |||
| 7505 | 5 | 1.65 | 30 | |||
| 1001 | 4″ | 100 | 4 | 1.6 | 30 | |
| 1002 | 4.5 | 1.9 | 30 | |||
| 1003 | 5 | 2.1 | 30 | |||
| 1004 | 5.5 | 2.4 | 30 | |||
| 1005 | 6 | 2.8 | 30 | |||
| 1251 | 5″ | 125 | 4.5 | 2.4 | 30 | |
| 1252 | 5 | 2.88 | 30 | |||
| 1253 | 6 | 3.2 | 30 | |||
| 1254 | 7 | 3.5 | 30 | |||
| 1501 | 6″ | 150 | 5 | 3 | 30 | |
| 1502 | 6 | 3.6 | 30 | |||
| 1503 | 7 | 4.5 | 30 | |||
| 1504 | 8 | 5.5 | 30 | |||
| 1505 | 9 | 6.3 | 30 | |||
| 1506 | 10 | 7.2 | 30 | |||
| 2001 | 8″ | 200 | 6 | 5 | 6/8/10 | |
| 2002 | 7 | 5.8 | ||||
| 2003 | 8 | 6.8 | ||||
| 2004 | 9 | 7.5 | ||||
| 2541 | 10″ | 254 | 8 | 10 | 6/8/10 | |
| 2542 | 10 | 12 | ||||
| 3051 | 12″ | 305 | 8 | 14 | ||
| 3052 | 10 | 15.5 |
