Fuel Dispenser Pump Hose

Fuel Dispenser Hose is designed for dispensing fuel in petroleum pumps. The inner tube is made from nitrile rubber and is resistant to gasoline and petroleum. Apart from this, our suction pipe is suitable for kerosene, diesel, lubricant, petrol, oil and gas. It’s light in weight, which makes it easy to install as well as maintain. Moreover, fuel dispenser hose is abrasion proof, compact in size, easy to use, accurate in dimensions and withstand high pressure as well as temperature.

Construction:

Tube: Nitrile synthetic rubber,smooth
Reinforcement: steel wire braid
Cover: Nitrile synthetic rubber,black,green,red,blue or yellow

Application:

Designed for general refueling equipment to convey diesel oil and other mineral oil.

Temperature: -40°C(-104°F) to 121°C ( +250°F)

Characteristics:

1.Designed for fuel up to 50% aromatic content
2.Weather and ozone resistant cover
3.C/W coupling SHF

Item code	I.D		O.D	W.P		B.P		Bend Radius	W
Item code	inch	mm	mm	bar	psi	bar	psi	mm	kg/m
016	5/8″	15.9	25.4	18	258	72	1032	160	0.59
019	3/4″	19.1	28.7	18	258	72	1032	190	0.67
025	1″	25.4	35.1	18	258	72	1032	240	0.89
